LW330FN

Overview

Power range: 132-180 kW. Euro II/III/IV/V emission standards. Maximum torque 900N.m at engine speed 1,200-1,600rpm. Engine weight: 620kg. Application: medium- and heavy-duty trucks.

Power Rating

Units: USMetric
Maximum Power 180 kW
Minimum Power 132 kW
Maximum Torque / Speed 900/（1200-1600） N·m / r/min

Emission Standards

Emissions Euro II/III/IV/V

General

Series WP6
Fuel Diesel
EngineType Inline 6-cylinder, four-stroke engine
Cylinder Number 6
Valve Number 2
Bore 105 mm
Stroke 130 mm
Displacement 6.75 L
Aspiration Turbocharged and intercooled
Compression Ratio 18:1
Combustion System Mechanical pump/Electronically controlled high-pressure common-rail

Engine Dimensions (Approximate. Final dimensions dependent on selected options)

Length 1256 mm
Width 572 mm
Height 972 mm
Weight – Net Dry (Basic Operating Engine Without Optional Attachments) 620±50 kg

Remarks: Product parameters and pictures are for reference only; subject to change without notice.

Item Parameter Unit
Rated load 5 t
Bucket capacity 3 m³
Dumping height 3100 mm
Dumping distance 1274 mm
Max.drawing force 158 kN
Max. traction 156 kN
Dimension 8010×3016×3350
Operating weight 16.5 t
Boom lifting time ≤5.6 s
Total time of three devices ≤9.9 s
Wheelbase 2900 mm
Min. turning radius (bucket outer) 6920 mm
Rated power ±35°
Travel speed I Gear (Forward/Backward) 0~11.5/16.5  km/h
II Gear (Forward) 0~38  km/h
Long boom parameter
Standard bucket Coal bucket
Bucket capacity 2.7m³ 3.5m³
Rated load 4.5t 4.0t
Dumping height 3520mm 3340mm
Dumping distance 1230mm 1380mm
Dimension 8300×3016×3350 8530×3016×3350
Min. turning radius (bucket outer) 7060mm 7080mm
Operating weight 16.6t 16.7

Overview

WP10 series engines are flagship products of Weichai for construction machinery. Displacement: 9.726L. Power range: 131-276kW. Euro Stage IIIa/II emission standards.

Power Rating

Units: USMetric
Maximum Power 200 hp148 kW
Minimum Power 156 hp115 kW
Maximum Torque / Speed （750-955）/（1000-1600） N·m / r/min

Emission Standards

Emissions Euro Stage IIIa/II

General

Series WP10
Fuel Diesel
Type Inline 6-cylinder, four-stroke engine
Cylinder Number 6
Valve Number 2/4
Bore 126 mm
Stroke 130 mm
Displacement 9.726 L
Aspiration Turbocharged and intercooled
Compression Ratio 17:1
Combustion System Electronically controlled high-pressure common-rail system/mechanical pump

Engine Dimensions (Approximate. Final dimensions dependent on selected options)

Length 1540 mm
Width 656 mm
Height 1208 mm
Weight – Net Dry (Basic Operating Engine Without Optional Attachments) 875 kg

Remarks: Product parameters and pictures are for reference only; subject to change without notice.
